Product Description
MSG-2174 FM Multiplex Signal Generator
MSG-2174 is an FM multiplex signal generator adopted a multiple module method.
Combination of DARC modulator, RDS modulator, and FM stereo modulator can be chosen depending on usage of user.
DARC-VICS/RTIC FM multiplex method and RDS/RBDS FM multiplex method are available by this one unit, moreover a stereo modulator can be installed in same casing.
By using application software attached to this unit, new data can be created and edited by a PC simply.
This unit can output the data by being downloaded.
Regarding DARC encoder function, we reduced its size by modifying specifications of MSG-2170/2173 and achieved cost reduction.
As for RDS function, usability for production line was prioritized because it is an existing method.
An FM-AM standard signal generator such as MEGURO MSG-2280 is required in order to generate RF signal from data which MSG-2174 encodes.
FEATURES
- RDS/RBDS, DARC, and Stereo modulator can be combined freely.
- Main Flame + RDS only
- Main Flame + RDS + Stereo Modulator
- Main Flame + DARC only
- Main Flame + RDS + DARC
- Main Flame + Stereo Modulator
- Main Flame + DARC + Stereo Modulator
- Main Flame + RDS + DARC + Stereo Modulator
SPECIFICATIONS
Main frame | |
Composite output signal | |
Output level | Max. 3.00Vp-p(0.00 to 3.00 0.01V step) |
S/N ratio | 80dB< |
Output impedance | 75Ω |
External signal mixing input | |
Input frequency range | 30Hz to 100kHz |
Input/Output gain | 1.0(+0, -0.5dB) |
Input impedance | 10kΩ |
Pilot input | |
Input level range | 1.0Vp-p to 3.0Vp-p |
Input impedance | 10kΩ |
Input data/clock | |
Input level range | TTL |
Input impedance | 10kΩ |
RDS | |
Output level | Max. 300mVp-p : 3.0Vpp=75kHz(100%) |
Output level setting | 0.0 to 10.0% (0.1% step) |
Subcarrier frequency | 57kHz ±2Hz |
Subcarrier distortion | 0.1% < (Output 3Vp-p ,DEV. 10%) |
Data modulation mode | DPSK 1.1875 kbps |
External data/clock input | TTL |
Bit error rate | PN9 |
Records | 00 to 10 (00 fixed pattern) |
DARC | |
Output level | Max. 450mVp-p : 3.0Vp-p = 75kHz(100%) |
L-MSK level control | Auto/Manual switching |
AUTO | Upper limit : 10.0% ,Lower limit : 4.0% |
MANUAL | 0.0 to 15.0% (0.1% step) |
Subcarrier frequency | 76kHz ±2Hz |
Subcarrier distortion | 0.1% < (Output 3Vp-p,DEV. at 10%) |
Data modulation mode | LMSK 16kbps Frequency shift : ±4kHz |
External data/clock input | TTL |
Bit error rate | PN9 |
Records | 00 to 10 (00 fixed pattern) |
Stereo Modulator | |
OUTPUT | |
Output level | Max. 3.57Vp-p : 3.0p-p=75kHz(100%) Pre-emphasis : OFF |
Output level setting | 0 to 125% (0.5% step) |
Internal modulation frequency | 400Hz,1kHz,6.3kHz,10kHz,15kHz,EXT. |
Modulation mode | L&R,MONO,MAIN,LEFT,RIGHT,SUB,OFF |
Pre-emphasis | OFF,25µs,50µs,75µs |
Frequency characteristics | 30Hz to 15kHz ±0.2dB |
Separation | 55dB > |
Distortion | 0.02% < (Output 3Vp-p,DEV. 100% ,at MONO) |
S/N ratio | 74dB > |
PILOT | |
Pilot signal | 19kHz ± 1Hz |
Output level setting | 0 to 15% (1% step) |
Pilot output | 1.0Vp-p |
EXT. AF input Frequency range | 30Hz to 15kHz |
Input level judgment accuracy | 2Vp-p±2% |
Input impedance | 10kΩ |
Interface | |
Serial interface | RS-232C: D-sub 9pin (male), USB : Type B (female) |
Parallel interface | GP-IB (Compliant with IEEE Std. 488-1975) |
General Data | |
Power requirements | AC 90 to 240V50/60Hz |
Power consumption | Max. 20VA (Full-featrued product) |
Dimensions | Approx. 420(W)×100(H)×370(D)mm |
Weight | Approx. 5kg |
Operating temp range | 0℃ to +40℃ |
Guarantee temperature range | +10℃ to +35℃ |
* | Specifications are subject to change without notice. |
